Single Stage
Single Stage
Showing all 8 results
-
Drop-In ReplacementNash Classic Premier SeriesNash Premier Series Replacements: NES NP Series Liquid Ring Vacuum Pumps and Compressors
NES Company Inc. offers the NP Series liquid ring vacuum pumps. With dual-cone, single-stage design, the Premier Series is capable of reaching up to 24.5” of Hg in vacuum and 3,500 to 11,180 CFM. NES Company Inc. NP Series vacuum pumps are designed and manufactured to be drop-in replacements of the Nash Classic Premier Series liquid ring vacuum pumps, renowned for their efficiency. NP Series pumps maintain the highest average CFM/HP ratio among large pumps, including the Nash Classic 904/905 and CL Series vacuum pumps. The difference is in the design of the inlet and outlet. Using a 45-degree angled inlet, the pump is optimized for high-velocity, high-capacity flow processes that require a maximum of 24.5″HgV. Constructed in standard cast iron with optional metallurgies available, the NP Series liquid ring vacuum pumps are factory performance-tested and include a 2-year warranty against manufacturing defects.
We have drop-in replacements for the Nash Classic Premier Series.
-
Drop-In ReplacementNASH Classic SCNash SC Series Replacements: NES NC Series – Single Stage, Single Cone, Liquid Ring Vacuum Pumps, and Compressors
NES Company is proud to offer our NC Series conical lobe design single stage liquid ring vacuum pumps and compressors. The 7.5-150 HP single stage liquid ring vacuum pumps have been designed to be drop-in replacements for classic Nash SC pumps. NES NC vacuum pumps and compressors are factory performance tested and include a 2-year warranty.
We have directly interchangeable parts with the NASH Classic SC.
-
Drop-In ReplacementNASH Classic CLNash CL Series Replacements: NES NL Series – Single Stage, Dual Cone, Liquid Ring Vacuum Pumps, and Compressors
NES Company is proud to offer our NL Series conical lobe design single stage liquid ring vacuum pump. These 20-550 HP single stage liquid ring vacuum pumps have been designed to be drop-in replacements for classic Nash CL series pumps. NES NL vacuum pumps are factory performance tested and include a 2-year warranty.
We have directly interchangeable parts with the NASH Classic CL.
-
Drop-In ReplacementNASH Classic Vectra XLNash XL Series Replacements: NES NX Series – Single Stage, Single Cone, Liquid Ring Vacuum Pumps, and Compressors
Our NX Series are designed as drop-in replacements for the Nash classic XL / GL series vacuum pumps and compressors. The single cone liquid ring vacuum pump and compressor is designed to have only one moving part to induce maximum mechanical stability with maximum reliability. We offer versions with capacities ranging from 60-940 CFM up to 28” Hg of vacuum and 30 psig of compression.
We have directly interchangeable parts with the NASH Classic Vectra XL.
-
Drop-In ReplacementNASH Classic 904 / 905Nash 904 / 905 Series Replacements: NES N904 Series – Single Stage, Dual Cone, Liquid Ring Vacuum Pumps and Compressors
Conical Lobe Liquid Ring Pumps & Compressors
NES Company is proud to offer our conical lobe design single stage liquid ring vacuum pumps. These 30-900 HP single stage liquid ring vacuum pumps have been designed to be drop-in replacements for Nash 904/905 series pumps. NES pumps are factory performance tested and include a 2-year warranty.We have directly interchangeable parts with the NASH Classic 904 / 905.
-
Drop-In ReplacementNASH Siemens L200 2BESiemens Nash L200 2BE Series Replacements: NES NBE Series – Single Stage, Port Plate, Liquid Ring Vacuum Pumps, and Compressors
Our NBE series vacuum pump is manufactured to be a drop-in replacement for the Siemens L200 2BE series pumps and compressors. This series is an ideal fit for industrial market customers looking for an upgrade in efficiency or a L200 2BE flat plate type vacuum pump replacement. NES NBE vacuum pumps and compressors are factory-tested and include a 2-year warranty.
We have directly interchangeable parts with the NASH Siemens L200 2BE.
-
Drop-In ReplacementSiemens 2BVSiemens L200 2BV Series Replacements: NES NCC Series – Single Stage, Port Plate, Liquid Ring Vacuum Pumps
Our NCC cast iron close-coupled vacuum pumps are the economical choice for small single stage close-coupled liquid ring vacuum pumps. These models are designed as drop-in replacements for Siemens 2BV series, Tuthill A series, and Dekker DV B-K series from 2-25 HP. Standard construction is cast iron with the Stainless Steel 304 impeller and Viton elastomer mechanical seal. These rugged pumps range from 18-350 CFM and span across a wide selection of vacuum levels for long-lasting and accurate service. NES NCC vacuum pumps are performance tested and include a 1-year warranty.
We have directly interchangeable parts with the Siemens 2BV.
-
Drop-In ReplacementNASH Classic AHF/MHFNash MHF / AHF Series Replacements: NES NHF Series – Single Stage, Port Plate, Liquid Ring Vacuum Pumps
Our high efficiency close-coupled liquid ring NHF Series vacuum pumps are an excellent choice, producing up to 40% more capacity per horsepower. These new premium 50-120 CFM vacuum pumps are coupled to high efficiency 3-7.5 HP IEC frame motors and have been designed from the ground-up to be interchangeable with Nash classic AHF and MHF series pumps. NES NHF series vacuum pumps are factory tested and include a 1-year warranty.
We have directly interchangeable parts with the NASH Classic AHF/MHF.
